As modern technology continues to advance, there is a corresponding need for more efficient storage systems. From your personal devices to enterprise data centres, being able to store more data easily is the long-term target. That’s where block storage comes in. This storage technology has evolved significantly over the decades, transcending the switch from bulky disks to efficient cloud-based solutions.
How has block storage continued to adapt to meet ever-growing business needs? What are the origins and what does the future hold for this technology? We’ll discuss all that and more below, but first.
What is Block Storage?
Block storage is a data storage technology where data is stored in individual blocks of equal sizes. Each block is assigned a unique identifier address. This means they can be managed individually, leading to flexible management and fast data retrieval from the blocks.
This storage technology ensures direct access to data, and expansion requires only additional storage disks. Hence, any data that needs to be accessed can be reached simply through its unique address. Since it allows quick data reading and writing, it’s ideal for systems that use huge amounts of data, such as virtual machines and databases.
Block storage uses both cloud storage technology and hard drives, with examples including SSDs (solid-state drives) and hard disks.
The Origin of Block Storage Technologies
Block storage technology has been around since efficient data storage and retrieval became a requirement shortly after computers were introduced. Block storage was developed when there was a need for faster data access and a more scalable storage system. Since the 1950s, there has been an increased need for more computer storage, with traditional storage methods like magnetic tapes no longer being able to do the job.
Punch cards and magnetic tapes store data in sequence. If you attempt to retrieve data, the computer proceeds to read the entire storage sequence. Not only would this take a long time, but it would also be tedious for large-scale operations. When the hard disk drive was developed, it allowed for non-sequential data retrieval. Hard disks stored data on spinning disks and were available in independent units rather than as a whole stream.
Each unit or block had its own unique identifier which allowed the computer to locate it directly instead of going through the whole data. One of the earliest block storage systems was the Model 350 from IBM, which allowed you to store 5 MB of data across 50 units, each one with its own address.
Evolution of Block Storage Systems
Significant advancements have happened to block storage systems. This section details how the technology has evolved from HDDs to SSDs.
1980s – 1990s
Data processing, enterprise computing, and networking witnessed increased growth from the 1980s through the 1990s. These required more advanced storage systems and led to a couple of important innovations.
For instance, the SCSI (Small Computer System Interface was introduced in 1986 as a standardized connection and transfer interface. It quickly became the preferred block storage solution as it allowed faster transfer between computers and storage devices.
RAID (Redundant Array of Independent Disks) Technology was another common block storage system. It transformed redundancy and performance handling in block storage systems, allowing the grouping together of hard drives as a unit. It also boosted read/write speeds and provided protection against disk failure.
By 1999, Storage Area Networks (SANs) were introduced in response to more challenges of storage management and scalability faced by enterprises. SANs were a new form of block storage that utilized high-performance networks and could be accessed or managed centrally by multiple systems simultaneously. This means multiple servers can share access to particular block storage.
The Shift to SSDs
Solid-state drives (SSDs) became more popular in the early 2000s. These block storage types store data with flash memory, unlike HDDs, which rely on magnetic disks and mechanical components.SSD storage devices existed as a whole without moving parts. The significance of this is speed and instantaneous data retrieval due to a lack of latency from mechanical components. It also means a lower failure risk and more reliability.
Compared to HDDs, SSDs will produce barely any heat, as they consume far less power. Another reason that makes them suitable for data centres and other highly demanding data storage and computing facilities. The SSD technologies have also improved over the years to allow greater capacities at reduced costs.
Modern Advancements
Block storage systems have continued to evolve into faster, more scalable, and flexible solutions to meet the needs of computing advancements. For instance, Non-Volatile Memory Express (NVMe) technology has been adopted as a standard for systems with highly demanding storage needs.NVMe provides a direct connection to the CPU over the PCIe interface, leveraging SSD speed. It is popular with AI/ML applications and slowly replacing older interfaces like SATA because of its lower latency and higher throughput.
Improvements in cloud computing have advanced cloud-based storage, with providers like Amazon Web Services (AWS), Google Cloud, and Microsoft Azure leading the race. Cloud-based storage can be managed easily from anywhere in the world without hardware management, making it perfect for a wide range of applications.
Enterprises have also adopted the use of hybrid block storage systems that combine SSDs, HDDs, and cloud-based solutions. This way, data can be stored cheaply by housing long-term data, and data is rarely accessed with older technologies like HDD. Other modern advancements include Software-Defined Storage (SDS), which operates programmatic data management, especially in multi-cloud or hybrid-cloud environments.
Conclusion
Block storage is a highly efficient data storage system with a wide range of applications due to its high performance and flexibility. As the technology continues to advance, we can expect even more flexible and scalable options that allow for easy integration into wider systems and setups.
However, the idea of automating block storage is also not beyond imagination. Not only has the idea been mentioned, but development is likely already ongoing, especially with advancements in related fields like machine learning and artificial intelligence. Experts believe that AI and MI can change the world, not just data storage.
